Raynox HD6600 .66X Super Wide Angle Lens

See all items by: Raynox

Click image(s) to enlarge.

You must Log in or Register to view pricing.

Item not reviewed (write a review…)

Quick Overview

Raynox HD6600 .66X Super Wide Angle Lens…

HD6600 .66X 43MM WIDE ANGLE LENS

The image distortion occurs more or less with a wideangle lens on, but this particular lens is especially made for Distortion Free（-1.3％） based on the sophisticated lens formula which produces a resolution power of 350-line/mm at center（MTF30%）. Especially designed for use with high-definition digital camera, and the lens is made of hi-index optical glasses, 3-group/3-element, fully coated. It's an ideal accessory lens for professionals and advanced amateurs shooting in tight place. There will be no reduction of light value when this conversion lens is attached on the camera's lens.

The original Raynox adapters are designed and made to suit the best physically and optically to the HD-6600PRO lens to obtain the optimum image quality like the pictures shown in our website. When the adapters of other makers are used with Raynox HD-6600PRO lens, the picture image quality could be slightly deteriorated, especially around the corners.

	Specifications & Measurements
	Magnification	Nominal 0.66x, Actual 0.66x Diagonal, 0.66x Horizontal
	Lens construction	3-group/3-element, Coated optical glass elements
	Image distortion	-1.3%(max.wideangle)
	Front Filter thread	72mm
	Mounting thread	37mm, 43mm, 46mm, 49mm, 52mm, 55mm, 58mm
	Dimensions (Height x Diameter)	43mm x 76mm/HD-6600PRO-37, 38mm x 76mm/HD-6600PRO-43, 40mm x 76mm/HD-6600PRO-46, 38mm x 76mm/HD-6600PRO-49, 40mm x 76mm/HD-6600PRO-52, 40mm x 76mm/HD-6600PRO-55, 36mm x 76mm/HD-6600PRO-58
	Weight	175g(6.2oz)/HD-6600PRO-37, 168g(5.9oz)/HD-6600PRO-43, 172g(6.1oz)/HD-6600PRO-46, 168g(5.9oz)/HD-6600PRO-49, 178g(6.3oz)/HD-6600PRO-52, 172g(6.1oz)/HD-6600PRO-55, 177g(6.2oz)/HD-6600PRO-58,
	Accessories	Case, Lens caps, Instruction manuals
